Catalogue



2016







Grade 5 Titanium Floating jib block:





80mm OD x 46mm ID 40mm wide with a 20mm wide grove - SWL 24,600kg



60mm OD x 35mm ID 25mm wide with a 12mm wide grove - SWL 11,000kg



50mm OD x 34mm ID 22mm wide with a 12mm wide grove - SWL 5,850kg



38mm OD x 25mm ID 18mm wide with a 10mm wide grove - SWL 4,500kg









Stanchions standard length 625mm

but can be made to what ever length required including 2 or 3 life line holes:



We make stanchions from aluminium, 316 stainless steel, titanium, and our new grade 9 titanium which is almost double the strength of our standard titanium stanchion









T12 Titanium Martin Breaker









Pipe cots /  Bunks:



Price on Request

3 or 4 sided carbon / aluminium or aluminium bunks incl. hinges, cover, purchase system and Spinlock Jammer



 New carbon sided ali corned bunk



 Our new carbon sided bunk with aluminium corners, with light weight black net cover



 standard carbon ali bunk



Our standard 4 sided carbon and aluminium bunk, with light weight black net cover
